UG-668

DIGITAL HEADER PAD LOOKUP TABLE

Table 5. Pinout for Digital Header 1 Pad (J20) on
Top Row (from Left to Right)
Pin No.
J20-2
J20-4
J20-6
J20-8
J20-10
J20-12
J20-14
J20-16
J20-18
J20-20
J20-22
J20-24
J20-26
J20-28
J20-30
J20-32
J20-34
J20-36
J20-38
J20-40
J20-42
J20-44
J20-46
J20-48
J20-50
Table 6. Pinout for Digital Header 2 Pad (J5) on
Top Row (from Left to Right)
Pin No.
J5-19
J5-17
J5-15
J5-13
J5-11
J5-9
J5-7
J5-5
J5-3
J5-1
EVAL-ADuCM350EBZ
Internal Connection
P2.1
P2.3
P2.5
P1.0
P1.2
P1.4
P1.6
P3.8
P3.3
P1.11
P1.13
P1.15
P2.11
P2.12
P2.15
P3.10
P2.13
P3.11
P3.0
P3.1
P3.5
P3.7
N/A
N/A
N/A
EVAL-ADuCM350EBZ
Internal Connection
N/A
N/A
N/A
N/A
P0.14
P0.12
P1.0
P4.1
P3.14
P3.12
Rev. A | Page 8 of 28
EVAL-ADuCM350EBZ User Guide
Bottom Row (from Left to Right)
Pin No.
J20-1
J20-3
J20-5
J20-7
J20-9
J20-11
J20-13
J20-15
J20-17
J20-19
J20-21
J20-23
J20-25
J20-27
J20-29
J20-31
J20-33
J20-35
J20-37
J20-39
J20-41
J20-43
J20-45
J20-47
J20-49
Bottom Row (from Left to Right)
Pin No.
J5-20
J5-18
J5-16
J5-14
J5-12
J5-10
J5-8
J5-6
J5-4
J5-2
Internal Connection
P2.0
P2.2
P2.4
P1.1
P1.3
P1.5
P1.7
P1.9
P3.9
P1.8
P1.10
P1.12
P1.14
P2.10
P2.9
P2.8
P2.7
P2.6
P2.14
P3.2
P3.4
P3.6
N/A
N/A
N/A
Internal Connection
N/A
N/A
N/A
N/A
P0.15
P0.13
P0.11
P4.2
P4.0
P3.13
