UG-668

GETTING STARTED

SOFTWARE INSTALLATION PROCEDURES

For software installation procedures, refer to the following
ADuCM350 software documentation for further details:
•
For more information about the EKSP LabVIEW® GUI,
refer to the EKSP user guide (ADuCM350_Evaluation_Kit_
Software_Platform.pdf) within the Documentation
folder of the software development kit.
•
For more information about the SDK firmware/debug
environment, refer to SDK user guide (ADuCM350BBCZ_
Software_Users_Guide.pdf) within the Documentation
folder of the software development kit and to the
software development kit quick start guide, UG-677.

EVALUATION BOARD SETUP PROCEDURES

1. Plug the
the
2. Plug the USB-SWD/UART-EMUZ board into J14 on the
ADuCM350
3. Plug the USB cable into the USB-SWD/UART-EMUZ board.
After the drivers are downloaded, you can begin communicating
with the board.
ADuCM350
Figure 2. EVAL-ADuCM350EBZ Setup
Rev. A | Page 4 of 28
EVAL-ADuCM350EBZ User Guide
ADuCM350 switch mux configuration board into
ADuCM350 evaluation board, EVAL-ADuCM350EBZ.
evaluation board, EVAL-ADuCM350EBZ.
