INSTALLATION
2.1

Gas Connections

Connections are as follows:
1. Sample Gas Inlet
¼" OD Swagelok
(100 narg (1450 psig) maximum supply pressure)
2. Sample Gas Outlet
¼" OD Swagelok
(Vent to atmosphere/low pressure flare. 7 barg (101 psig) maximum back
pressure)
3. Letdown Gas Vent
¼" OD Swagelok
(Vent to atmosphere)
NOTE: All tube fitting connections are made directly onto the isolation ball
valves.
2.2

Power Supply Connection

A single-phase AC mains power supply is required to operate the Sampling System.
The factory-set power supply voltage is indicated on a yellow label located on the rear
panel. NOTE: The user cannot change the specified power supply voltage.
The Condumax II analyzer is powered via the mains from the analyzer conduit.
6
Ensure that the process sample gas supply line is well flushed
through to clear any liquids and debris present, prior to
connection to the Sampling System.
tube fitting
®
tube fitting
®
tube fitting (NEC version)
®
Wire Color
Brown
Blue
Green/Yellow
Table 1
Condumax II Sampling System -
NEC Compatible IOM Manual
Power Connection
Line Voltage
Neutral
Earth
Wire colors
97525, Issue 1, November
