Appendix A Technical Specifications
General
Gas Wetted Materials
Sample Gas
Sample Gas Pressure
Sample Gas Flow rate
Bypass Gas Flow Rate
Filters
Enclosure
Sample Gas Connections
Cable Entries
Power Supply
Power Consumption
Operating Temperature
Weight
Optional
Enclosure Cooling
(Optional)
Enclosure Heating
18
316L stainless steel with Viton
Hydrocarbon/Natural Gas
10 to 100 barg (145 to 1450 psig)
HCdp range = 0.02 to 0.13 m³/hour (0.3 to 2.2 Nl/min)
(nominal setting = 0.06 m³/hour (1 Nl/min))
H Odp range = 0.04 to 0.4 m³/hour (0.6 to 6.6 Nl/min)
2
(nominal setting = 0.2 m³/hour (3.3 Nl/min))
Range = 0.04 to 0.4 m³/hour (0.6 to 6.6 Nl/min)
(nominal setting = 0.2 m³/hour (3.3 Nl/min))
Coalescing & membrane filter
304/316 stainless steel fitted with wall-mounting brackets
(Ingress protection rated to IP66)
¼" OD Swagelok twin ferrule tube fittings
®
Conduit with individual wires
110 to 120 V AC 60 Hz
400 W max
-20 to +60°C (-4 to +140°F) <95%RH
(+40°C (+104°F) max continuous operation)
75kg (165lbs) max
Compressed air via Vortex tube controlled by a mechanical
thermostat. Maximum cooling capacity = 410W @ internal temp
of +35°C (+95°F) and external temp of +55°C (+131°F) with
maximum air input temp of +40°C (+104°F)
100 W Heater with fixed preset +20ºC or +40ºC set-point thermostat
