CELLTRON MAX
Model Number
CMA-7000 CELLTRON MAX (analyzer); CELLTRON MAX Kit
Applications
Tests individual lead-acid cells or monoblocs (up to 16 volts)
in any common configuration
Voltage
1.5–18.0 Vdc
Conductance
100–19,990 siemens
Test Data Storage
500 string locations of 480 test results stored internally
Accuracy
± 2% across test range
Voltmeter Resolution:
5 mV
User Programmable Functions
• Preset values for over 250 battery types
• Low voltage alarm setting
• Low conductance warning
• Low conductance failure
• Test mode (pushbutton/autostart)
Calibration
Auto-calibration before every test; no future calibration
required
Connectorized Test Cable Options
• Dual contact clamps
• Dual contact probes
• Custom cables by quotation
Power Requirements
7.2 V, 2500 mAh, NiMH internal swappable battery and
charger
Midtronics Inc. 7000 Monroe Street Willowbrook, IL 60527

Product Specifications

Display
LCD—FSTN (x2)
66.52 mm x 33.25 mm (2.62 in x 1.31 in), 128 x 64 pixels, 40-
degree viewing angle, contrast ratio 8, green LED backlight
Keypad
Stainless-steel dome, polycarbonate overlay, 1,000,000
actuations
Data Transfer
Infrared protocol, half -duplex IrDA protocol, USB drive
Environmental Operating Range
0 to +40 ˚C, 95% relative humidity, non-condensing
Storage Temperature
–20 to 82 ˚C
Over-Voltage Protection
• Auto-reset disconnect
• Reverse polarity protected
Housing Material
Acid resistant ABS plastic santoprene overmold
Analyzer Dimensions
280 mm x 105 mm x 80 mm (11 in x 4 in x 3 in)
Case Dimensions
485 mm x 395 mm x 180 mm
19 in x 15.5 in x 7 in
Analyzer Weight
1.18 kg (2.6 Ib)
Celltron MAX Kit Shipping Weight
Approximately 5 kg (11 Ib)
