Data

Kit accessories

Item
MAX Clamps
MAX Probes
Interchangeable Cable
Probe-extender kit
Midtronics printer with an AC
adapter (120 Vac, 60 Hz)
AC adapter, 120 Vac, 60 Hz
(Optional adapter: 110 to 240 Vac,
50/60 Hz)
Spare NiMH battery pack
USB Cable
CELLTRAQ Single User CD & CMA
CELLTRAQ Tester Interface CD
For technical assistance and to purchase replacement parts, call Midtronics Customer Service. (See "Patents, Limited Warranty, Service. " )
www.midtronics.com
127 mm (5 in) clamps and 50.8 mm (2 in) openings with built-in LED lights
Cables with 152.4 mm (6 in) probes with rotating heads and 27.7 mm (0.5 in) tips for quick
contact with large jar posts
139.7 mm (5.5 in) tester cables with locking connectors for interchangeable clamps and
probes
Extension rods for reaching and testing jars in confined spaces
Handheld printer with infrared receiver for data transmitted by the CELLTRON MAX;
includes battery charger (output 10.2 Vdc, 800 mA) for charging the printer's NiMH
batteries
Charger for the analyzer's internal NiMH battery pack (output 7.2 Vdc, 700 mA)
7.2 V, 2500 mAh NOTE: Apply sufficient force on the battery pack for the end clips to
catch to the case.
USB link from the CELLTRON MAX to a Windows-based computer
Software for managing test data
10
•
Description
