Chapter 1 S3740 Introduction; Appearance Description For Standard Configuration - Bdcom S3740 Installation Manual

Chapter 1 S3740 Introduction

The section describes the characteristics and parameters of
overview of .
S3740

1.1 Appearance Description for Standard Configuration

The built-in ports of S3740 are: 32 gigabit Ethernet RJ45 ports, 8 10G Ethernet SFP+
ports and 1 Console port. See table 1-1.
Port
Gigabit Ethernet TX port
10G Ethernet optical port
Console port
Table 1-2 Parts at the front template of the S3740 switch
No. Abbrev.
1-32
1
2 TE1-TE8
3 CONSOLE
4 SYS
Table 1-1 Attributes of the built-in port
10/100/1000M
auto-identification,
indicators
SFP+ interface, 10G optical module, LINK/ACT indicator
A rate of 9600bps, mini USB interface
Figure 1-1 Front template of the S3740 switch
Name
32 1000Base-T ports
8 10G SFP+ ports
Console port
System indicator
S3740 Hardware Installation Manual
S3740
Attribute
auto-adaptation,
UTP (RJ45) TX
Description
Forwards the 10/100M/1000M Ethernet
electrical signals.
Forwards the 10000M Ethernet optical
signals.
Manages the switch locally.
If the indicator is always on, the system
is normally started up.
If the indicator flickers, the system
and gives an
MDI/MDIX
ports, LINK/ACT
