Deutschmann Automation GmbH & Co. KG Implemented protocols in UNIGATE® MB
8.9 Protocol „Universal Modbus ASCII Master/Slave"
®
The fieldbus data exchange for Modbus ASCII is identical with RTU. The UNIGATE automati-
cally transmits the data in ASCII format on the serial side.
8.9.1

Appendix

8.9.1.1

Example Configuration 1:

®
Hardware UNIGATE CL-PROFIBUS
® ® ®
