Implemented protocols in UNIGATE® MB
8
Implemented protocols in UNIGATE
®
UNIGATE
MB is supplied with the Script "Universal Script Deutschmann". The configuration of
the protocols is carried out in the configuration mode (see Chapter 4.1) with the software
WINGATE. See "Instructions UNIGATE
be found on our website under Support/Downloads/Manuals.
Attention:
If a Reset Device is carried out it is possible (depending on the firmware
version of the UNIGATE
must be played in again.
The Script can be found on the Deutschmann Support-DVD in the folder
\Software\ProtocolDeveloper\Example\Universal\.
8.1
Protocol: Transparent
The data is transferred bidirectional from the UNIGATE
8.1.1
Data structure
On the RS-entry side the timeout time of 2 ms is firmly set. If no more data is received within the
timeout period, then the data that has been received so far is transferred to the bus.
If less data is received through Rx then configured by the GSD-file (I/O-length), then the rest is
complemented with ZERO.
Too much data received will be cut off.
8.2
Protocol: Universal 232
The protocol designation "Universal 232" and the relation to the
"RS232-interface" in the description have eveloped over the years. The
protocol also works with RS422 and RS485 though!
8.2.1
Data structure
18
UNIGATE
®
CL - Configuration with WINGATE". The PDF can also
®
) that the "Universal Script" will get lost and
®
fieldbus gateway UNIGATE
Deutschmann Automation GmbH & Co. KG
®
MB
®
.
®
®
MB - EtherCAT
V. 1.4
17.7.17
