How to Programme
22-61 Broken Belt Torque
Range:
10 % [0 - 100 %] Sets the broken belt torque as a percentage
*
22-62 Broken Belt Delay
Range:
10 s [0 - 600
s]
22-75 Short Cycle Protection
Option:
6 6
[0] Disabled Timer set in parameter 22-76 Interval between
*
[1] Enabled Timer set in parameter 22-76 Interval between
22-76 Interval between Starts
Range:
Size
related - 3600 s]
*
22-77 Minimum Run Time
Range:
0 s [ 0 - par.
*
22-76 s]
NOTICE
Does not work in cascade mode.

6.1.5 Main Menu Mode

Both the GLCP and NLCP provide access to the main menu
mode. Select the Main Menu mode by pressing [Main
Menu]. Illustration 6.18 shows the resulting readout, which
appears on the display of the GLCP.
Lines 2 to 5 on the display show a list of parameter groups
which can be selected by toggling [
88
Function:
of the rated motor torque.
Function:
Sets the time for which the broken belt
conditions must be active before carrying out
the action selected in parameter 22-60 Broken
Belt Function.
Function:
Starts is disabled.
Starts is enabled.
Function:
[ par. 22-77 Sets the time desired as minimum
time between 2 starts. Any normal
start command (Start/Jog/Freeze) is
disregarded until the timer has
expired.
Function:
Sets the time desired as minimum run time
after a normal start command (start/jog/freeze).
Any normal stop command is disregarded until
the set time has expired. The timer starts
counting following a normal start command
(start/jog/freeze).
A coast (inverse) or an external interlock
command overrides the timer.
▲
] and [
Danfoss A/S © Rev. 06/2014 All rights reserved.
Operating Instructions
Illustration 6.18 Display Example
Each parameter has a name and number which remain the
same regardless of the programming mode. In the Main
Menu mode, the parameters are divided into groups. The
first digit of the parameter number (from the left) indicates
the parameter group number.
All parameters can be changed in the Main Menu. The
configuration of the unit (parameter 1-00 Configuration
Mode) determines other parameters available for
programming. For example, selecting closed loop enables
more parameters related to closed loop operation. Option
cards added to the unit enable more parameters
associated with the option device.

6.1.6 Parameter Selection

In the Main Menu mode, the parameters are divided into
groups. Press the navigation keys to select a parameter
group.
The following parameter groups are accessible:
Group no.
0-**
1-**
2-**
3-**
4-**
5-**
6-**
8-**
9-**
10-**
11-**
13-**
14-**
15-**
16-**
18-**
20-**
▼
].
21-**
22-**
23-**
25-**
26-**
1107 RPM 3.84 A
Main menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
Parameter group
Operation/Display
Load/Motor
Brakes
References/Ramps
Limits/Warnings
Digital In/Out
Analog In/Out
Comm. and Options
Profibus
CAN Fieldbus
LonWorks
Smart Logic
Special Functions
FC Information
Data Readouts
Data Readouts 2
FC Closed Loop
Ext. Closed Loop
Application Functions
Time Actions
Cascade Controller
Analog I/O Option MCB 109
