Standard Feature Details
Addressable operation is provided by an IDNet
signaling line circuit (SLC) capable of communicating to up
to 200 addressable devices (points). Addressable devices
include: TrueAlarm smoke detection, heat detection, and
duct detection; supervised addressable modules for single
and multiple contact monitoring, manual stations, isolation
modules, and a remote signal module (see list on page 4.)
(Please note that this panel provides a limited TrueAlarm
operation feature set. For larger applications that require the
full complement of TrueAlarm features, contact your local
Simplex product supplier.)
Two, 2 A On-Board NACs
polarity operation, selectable as Class A or Class B, with
electronic control and overcurrent protection. Operation is
selectable for synchronized strobe or SmartSync
horn/strobe two wire operation. Horn control can be
selected at the panel for: Temporal pattern coding, Steady
On, Slow March Time of 20 beats per minute (BPM), or
Fast March Time of 120 BPM. Note: When selected for
SmartSync horn/strobe control, March Time produces
60 BPM.
The 24 VDC Auxiliary output
for system use. (Auxiliary output current is counted for
total power supply capacity.)
Standard Auxiliary Relay Outputs.
are available, selectable as normally open or normally
closed, rated 2 A @ 30 VDC per below:
Aux Relay 1 is normally assigned to General Alarm
operation but is programmable (see page 7)
Aux Relay 2 (Trouble) is energized when Normal and is
de-energized with a Trouble condition.

Product Selection

Control Panel
Model Color Description
4008-9102 Beige
Standard fire alarm control panel
4008-9101 Red
4008-9122 Beige
Fire alarm control panel with 24 LED
Annunciator on front door
4008-9121 Red
Option Modules
Model Description
4008-9801 Expansion Power Supply; 3 A, with 2 NACs, 120/240 VAC, 50/60 Hz
4008-9802 Expansion Relay Module; 3 relays selectable as either N.O. or N. C.
4006-9805* City Circuit Modules with disconnect switch
4006-9806* City Circuit Modules without disconnect switch
* These City Circuit modules are also used on the 4006 Series control panels.
Accessories
Model Description
2975-9811 Beige semi-flush trim kit; 1
2975-9812 Red semi-flush trim kit; 1
Beige External Battery Cabinet for up to 25 Ah batteries; mounts close-nippled to control panel cabinet;
4009-9801
dimensions = 16 ¼" W x 13 ½" H x 5 ¾" D (413 mm x 343 mm x 146 mm)
Batteries, 12 Volt (select one battery model per system standby requirements; order quantity of two)
Model Size Model
2081-9272 6.2 Ah 2081-9288 12.7 Ah
2081-9274 10 Ah
provide conventional reverse
provides up to 500 mA
Two relay outputs
7
⁄ " (37 mm) wide; includes four corners and trim pieces for top, bottom, and sides
16
7
⁄ " (37 mm) wide; includes four corners and trim pieces for top, bottom, and sides
16
Size Location
For cabinet mount
Standard Feature Details (Continued)
On-Board Dual Line DACT.
for Contact ID, SIA, 3/1, 4/2, and BFSK formats.
Reporting includes Alarm, Supervisory, Trouble, and AC
Failure. Operation includes automatic 24 hour test and
programmable power fail report delay.
Power Supply and Battery Charger.
is 3 A @ 24 VDC for panel use. The temperature
compensated battery charger (sealed lead-acid batteries
only) is rated for up to 25 Ah batteries per UL 864 and up
to 12.7 Ah per ULC-S527. (Up to 12.7 Ah batteries fit in
the cabinet, larger batteries require an external cabinet.)
Panel electronics can measure and display voltage and
current for the power supply, batteries and the battery
charger (standard and expansion power supply). Depleted
battery trouble is monitored and annunciated and depleted
battery cutout can be selected. Active battery status
monitor supervises charger operation.
Optional Feature Details
Expansion Power Supply.
24 VDC, two additional 2 A NACs, and an additional
auxiliary power output of 500 mA. Output operation is the
same as on the standard power supply.
Expansion Relay Module.
each for Alarm, Supervisory, and Trouble conditions.
Each is jumper selectable as N.O. or N.C. Contacts are
rated 2 A @ 30 VDC. Location is the same as for the City
Circuit Modules.
City Circuit Modules.
or without on-board disconnect switches, depending on
local requirements (either type can be disconnected
through the front panel under password control).
Connections are for Remote Station (reverse polarity) or
Municipal Master (local energy). Reporting includes
Alarm, Supervisory, and Trouble.
Listings Standard Feature Summary
SLC with 200 addressable points,
MEA
2 Class B/Class A NACs, 3 A power
UL, FM, &
supply with battery charger; on-board
CSFM
DACT; for input voltage of
ULC
120/240 VAC, 50/60 Hz (autoselect)
Select one if required
Select one if required
Model Size Location
2081-9275 18 Ah
Requires 4009-9801 External Battery
Cabinet (UL listed only)
2081-9827 25 Ah
2
Operation can be selected
DC power output
Provides 3 A total @
Provides three relays, one
These modules are available with
S4008-0001-8 8/2012
