Reference

This section contains reference information for the MVC 121 Plus, including:
•
•
•

Mounting

The 1U high, quarter rack width, 3-inch deep MVC 121 Plus stereo mixer can be:
•
•
•
•

Tabletop Use

Each MVC 121 Plus comes with rubber feet (not installed). For tabletop use, attach a
self-adhesive rubber foot to each corner of the bottom of the unit.

UL Rack Mounting Guidelines

The following Underwriters Laboratories (UL) guidelines pertain to the safe installation of the
MVC 121 Plus in a rack.
1.
2.
3.
4.
5.
Mounting
Firmware Loader
MVC 121 Plus Hardware Reset Modes
Set on a table
Mounted on a rack shelf
Mounted under a desk or tabletop
Mounted on a projector bracket
Elevated operating ambient temperature — If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment may be greater
than room ambient temperature. Therefore, install the unit in an environment compatible
with the maximum ambient temperature (Tma = +122 °F, +50 °C) specified by Extron.
Reduced air flow — Install the equipment in a rack so that the amount of air flow
required for safe operation of the equipment is not compromised.
Mechanical loading — Mount the equipment in the rack so that a hazardous
condition is not achieved due to uneven mechanical loading.
Circuit overloading — Connect the equipment to the supply circuit and consider the
effect that circuit overloading might have on overcurrent protection and supply wiring.
Appropriate consideration of equipment nameplate ratings should be used when
addressing this concern.
Reliable earthing (grounding) — Maintain reliable grounding of rack-mounted
equipment. Pay particular attention to supply connections other than direct connections
to the branch circuit (e.g. use of power strips).
MVC 121 Plus • Reference 48
