EXTRON MVC121 Plus
Overview:
There are many uses of this driver, however the main purpose is to allow an installer to
easily overlay and mix up to 2 microphones (more if using another mixer in addition to
the MVC121 Plus) with program audio in a conference room scenario.
Features:
-2-Way RS-232 communication
-Discrete Volume & Mute Control & Feedback
-Easily Mix Up to 2 Microphones over Program Audio
-Includes 3 easy-to-use experience buttons for controlling microphone mute and vol-
ume levels via a Control interface
-Includes 1 universal microphone experience button for other applications
-Includes 3 Contact sensors to use for various programming events.
Installation:
Here is the suggested method of configuring the driver:
*FIRST* *IMPORTANT*
Load the saved MVC121+ configuration file (Included) into your MVC121 Plus to
properly configure the inputs, outputs, and gain levels of the MVC121 Plus
--Then--
Place the MVC121 Plus and microphone experience drivers into your Control4 driver
directory. (Typically C:\Users\yourusername\Documents\Control4\Drivers)
Create 1 room:
A) Conference Room
Add the MVC121 Plus driver to the project
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Extron electronics MVC121 Plus
Summary of Contents for Extron electronics MVC121 Plus
- Page 1 Installation: Here is the suggested method of configuring the driver: *FIRST* *IMPORTANT* Load the saved MVC121+ configuration file (Included) into your MVC121 Plus to properly configure the inputs, outputs, and gain levels of the MVC121 Plus --Then-- Place the MVC121 Plus and microphone experience drivers into your Control4 driver directory.
- Page 2 “Program Input (Input 3)” on the MVC121 Plus. In this example, the television audio output is connected to the MVC121 Plus. Set the MVC121 Plus as the Audio endpoint 1, Audio Volume 1 endpoint, Video Volume 1 endpoint, and Video's Audio endpoint 1 endpoints for the Conference Room: Included in this driver package are 4 microphone experience buttons that are used to control microphone levels and mute status from any Control4 navigator.
- Page 3 “Microphone – Button (Volume Down)” drivers to the project. Bind the Experience Buttons to the corresponding BUTTON_LINK connections on the MVC 121 Plus Make a physical and programming connection between the serial connection on the MVC121 Plus and an open serial port on your Control4 devices.
- Page 4 *IMPORTANT* Connect the MVC121 Plus Pinouts according to the manual to the proper RS-232 pinouts on the Control4 controller… If you are not able to properly communicate with the MVC121 Plus, you may want to switch from strait-through to NULL wiring.
- Page 5 2) Bind the BUTTON_LINK connections on the MVC121 Plus driver to Keypad buttons to control volume and mute features of the microphones. Don’t forget to set the color of the Button LEDs to: a. LED Behavior = “Follow Connection” b. On Color = Color you prefer LED to be when Mute is ON c.
- Page 6 Kill All Timers: Forces all timers within the driver to expire. Use if it is determined the MVC121 Plus has stopped responding to commands. Limitations: -Because of the limited volume range of the MVC121 Plus (-12db to 24db in 1db increments), you will notice volume increments will go up my 3ish % when you adjust...
- Page 7 the volume with Control4. Additionally, you may notice that when you set a Maximum volume level via the properties page, the volume level you set might change slightly to the nearest 3 percentage. Additionally, the slider on Control4 navigators may be slightly different than the actual volume levels due to rounding errors.
