Gain

The Gain control block monitors and adjusts the fixed
output. The channels can be adjusted from -24 dB to +12 dB
with a step resolution of 0.1 dB.
The L/R channels can be adjusted and muted individually unless
they are ganged. When the Gang button is active (red), the
level controls track each other and pressing either Mute button
mutes or unmutes both channels.
The Polarity buttons reverse the polarity of the respective left
and right output signal.
The OK button accepts settings and closes the dialog with a
single click, while the Cancel button ignores changes and
closes the dialog.
MVC 121 Plus • Operation 27
