Software Control

This section describes the control software for the MVC 121 Plus, including:
•
•
•
Software Control
The MVC 121 Plus can be controlled using the DSP Configurator software, SIS commands
through HyperTerminal or DataViewer.
The MVC has the following connection options:
•
•

Windows-based Program Control

The DSP Configurator control program is compatible with Windows 2000 and later
Windows versions, and provides remote control of the input gain and attenuation, output
volume output adjustment, and other features.
DSP Configurator can control the MVC 121 Plus via any of the two control ports, RS-232 or
USB.
Download DSP Configuration from the Extron website at
1.
2.
3.
4.
5.
Software Control
Windows-based Program Control
DSP Configurator Program
RS-232 — One single stack 6-pole, 3.5 mm captive screw connector is used for
bidirectional RS-232 (±5 V) serial control.
See Rear Panel Features
port.
USB 2.0 — A Mini B-type USB connector located on the front panel provides
high-speed USB 2.0 connectivity to a host computer, backward compatible to 1.0
Click DOWNLOAD to view the drop-down menu.
Select Software.
Select the letter D from the alphabetical list.
Scroll to DSP Configurator.
Click Download.
on page 4, for additional details on connecting the RS-232
www.extron.com.
MVC 121 Plus • Software Control
.
