Chapter 1: SP623 Board Features and Operation
Table 1-9: User DIP Switches
User Push Buttons (Active High)
[Figure
SW5 and SW6 are active-High user push buttons that are connected to user I/O pins on the
FPGA, as identified in
by the user.
Table 1-10: User Push Buttons
User Test I/O
[Figure
A standard 2 x 6, 100-mil pitch header (J44) brings out 6 FPGA I/O for test purposes.
Table 1-11
Table 1-11: User Test I/O
20
FPGA Pin
Net Name
J26
SW1
J25
SW2
K26
SW3
K24
SW4
G26
SW5
G25
SW6
H26
SW7
H24
SW8
1-2, callout 15]
Table
1-10. These switches can be used for any purpose determined
FPGA Pin
Net Name
M26
PB_SW1
M24
PB_SW2
1-2, callout 16]
lists these pins.
FPGA Pin
U1
IO_L40N_M3DQ7_3_U1
U2
IO_L40P_M3DQ6_3_U2
V1
IO_L39N_M3LDQSN_3_V1
V3
IO_L39P_M3LDQS_3_V3
AA13
IO_L36N_2_AA13
AB13
IO_L36P_2_AB13
www.xilinx.com
Reference
Designator
SW7
Reference
Designator
SW6
SW4
Net Name
J44 Pin
2
4
6
8
10
12
SP623 Board User Guide
UG751 (v1.0) May 22, 2010
