Appendix A: Default Jumper Positions
Table A-1: Standard Shunts (Cont'd)
Connector
J37 FMC2 JTAG
Notes:
These entries are not visible in the PCB silkscreen labels.
1.
Table A-2: Digital Power Shorting Plugs
36
Name
Connector Name
J3 MGTAVCCPLL
J30 VCC3V3
J31 VCC2V5
J102 VCCINT
J104 VCCAUX
J105 VCCO
www.xilinx.com
Shunt Position
Installed
Shorting Plug
Position
Installed
Installed
Installed
Installed
Installed
Installed
Quantity Pins (Jumper Label)
1 2–3
