Appendix C. Reference

Specifications

Electrical Connections
Approvals
Power Requirements
Physical Dimensions
Weight
Operating Temperature
Surge Suppression
Humidity
(Specifications subject to change without notice)

Appendix C.1.1. Compliance with UL Regulations

For UL compliance, the following instructions must be met when operating ProtoCessor.
•
The units shall be powered by listed LPS or Class 2 power supply suited to the expected
operating temperature range.
•
The interconnecting power connector and power cable shall:
o
Comply with local electrical code
o
Be suited to the expected operating temperature range
o
Meet the current and voltage rating for ProtoCessor
•
Furthermore, the interconnecting power cable shall:
Be of length not exceeding 3.05m (118.3")
o
o
Be constructed of materials rated VW-1, FT-1 or better
•
If the unit is to be installed in an operating environment with a temperature above 65 °C, it should
be installed in a Restricted Access Area requiring a key or a special tool to gain access.
•
This device must not be connected to a LAN segment with outdoor wiring.
One 3-pin Phoenix connector with RS-485 port (+ / - / gnd)
One Ethernet 10/100 BaseT port
CE Certified; TUV approved to UL 916, EN 60950-1,
EN 50491-3 and CSA C22-2 standards; FCC Class A Part 15;
DNP 3.0 Conformance Tested; RoHS Compliant; CSA 205 Approved
BTL Marked
5V DC
6.9 x 3.0 x 2.0 cm (2.7 x 1.2 x 0.8 in.)
0.03 kg (0.07 lbs)
-40°C to 75°C (-40°F to167°F)
EN61000-4-2 ESD EN61000-4-3 EMC EN61000-4-4 EFT
5 - 90% RH (non-condensing)

Figure 25: Specifications
