USE PROTOCESSOR WEB CONFIGURATOR TO SETUP THE GATEWAY

5.1

Connect the PC to ProtoCessor via the Ethernet Port

•
Connect a CAT5 Ethernet cable (Straight through or Cross-Over) between the local PC and
ProtoCessor.
•
The Default IP Address of ProtoCessor is 192.168.1.24, Subnet Mask is 255.255.255.0. If the PC
and ProtoCessor are on different IP Networks, assign a static IP Address to the PC on the
192.168.1.xxx network.
For Windows 10:
Right click on
>
Right-click on Local Area Connection > Properties
Highlight
Use the following IP Address:
Click
> >
>
twice.
