Appendix A. Troubleshooting; Lost Or Incorrect Ip Address; Figure 18: Ethernet Port Location - SMC Networks ProtoCessor FPC-ED2 Startup Manual

Appendix A. Troubleshooting

Lost or Incorrect IP Address

•
Ensure that FieldServer Toolbox is loaded onto the local PC. Otherwise, download the
FieldServer-Toolbox.zip via the Sierra Monitor Resource Center
•
Extract the executable file and complete the installation.
•
Connect a standard CAT5 Ethernet cable between the user's PC and ProtoCessor.
•
Double click on the FS Toolbox Utility and click Discover Now on the splash page.
•
Check for the IP Address of the desired gateway.
•
If correcting the IP Address of the gateway: click the settings icon
gateway, then click Network Settings, change the IP Address and click Update IP Settings to
save.
Leonard Valve ProtoCessor Start-up Guide

Figure 18: Ethernet Port Location

Page 21 of 32
Software Downloads.
Ethernet Port
on the same row as the
