3

SETUP FOR PROTOCESSOR

3.1

Record Identification Data

Each ProtoCessor has a unique part number located on the side or the back of the unit. This
number should be recorded, as it may be required for technical support. The numbers are as
follows:
ProtoCessor FPC-ED2
•
FPC-ED2 units have the following 2 ports: RS-485 + Ethernet
3.2

Point Count Capacity and Registers per Device

The total number of Registers presented by the device attached to the ProtoCessor cannot
exceed:
FPC-ED2-1145
Valve
3.3

Configuring Device Communications

3.3.1 Input COM Settings on the Device Connected to the ProtoCessor

•
The connected serial device MUST have the same Baud Rate, Data Bits, Stop Bits, and
Parity settings as the ProtoCessor.
•
Figure 4 specifies the device serial port settings required to communicate with the ProtoCessor.
Protocol
Baud Rate
Parity
Data Bits
Stop Bits
Model
FPC-ED2-1145

Figure 1: ProtoCessor Part Numbers

Part number

Figure 2: Supported Point Count Capacity

Devices

Figure 3: Registers per Device

Port Setting

Figure 4: COM Settings

Page 8 of 32
Leonard Valve ProtoCessor Start-up Guide
Part Number
Total Registers
1,500
Registers Per Device
41
Device
PSP
9600
None
8
1
