6.2
Replacing the Sensor
In case of severe contamination or a malfunction, the sensor can
be replaced.
Precondition
Gauge deinstalled (→
Unscrew the hexagon socket screws and remove the
sensor without twisting it.
Place the new sensor without twisting it and lock it with the
screws.
tina60e1-a
(2011-04)
49).
2 mm
53
