Inficon PSG550 Operating Manual page 13

RS232C / RS485 interface
Transmission rate
Data format
For further information on the RS232C / RS485C interface
→
[3].
DeviceNet interface
Specification, data format,
communication protocol
Interface, physical
Data rate (adjustable via <RATE>
switch)
Node address (MAC ID)
(Adjustable via <ADDRESS>,
<MSD>, <LSD> switches)
DeviceNet connector
Cable
Cable length, system wiring
For further information on the DeviceNet interface →
tina60e1-a (2011-04)
57600 baud (default)
binary
8 data bits
one stop bit
no parity bit
no handshake
→ "Power Connection"
→
[6]
CAN bus
125 kBaud
250 kBaud
500 kBaud (default)
<P> (125 kBaud,
250 kBaud, 500 kBaud
programmable via
DeviceNet, →
0 ... 63dec (63dec default)
<P> (0 ... 63 programmable
via DeviceNet, →
Micro-Style, 5-pin, male
shielded, special DeviceNet
cable, 5 conductors
→ 32, →
[7]
according to DeviceNet
specifications, →
[4])
[4])
[6], [7]
[4]
13
