Profibus Connector

If no Profibus cable is available, make one according to the
following diagram. Connect the Profibus cable.
1
6
Pin 1, 2
Pin 3
Pin 4
Pin 5
1)
Only to be connected if an optical link module is used.
2)
Only required as line termination for devices at both ends of bus cable
( →
Profibus cable
tina60e1-a (2011-04)
5
D-Sub, 9-pin, male, soldering side
9
Do not connect
RxD/TxD-P
1)
CNTR-P
2)
DGND
[9]).
2)
Pin 6 VP
Pin 7, 9 Not connected
Pin 8 RxD/TxD-N
