2.

PRODUCT DESCRIPTION

1. Wheel with Brakes
2. H shape metal Base
3. Column
4. Swivel arm
5. Suspension arm
6. Swivel Arm Locking Knob
7. Suspension arm movement locking knob
8. Coupling movement locking knob
9. Inclined coupling
10. Inclined coupling movement knob
11. Suspension arm hydraulic movement lock
12. Suspension arm spring tension adjustment
13. Swivel arm cover
14. Binocular head with eyepieces
2
6137000-795
13
4
23
22
3
2
1
Prima ENT/DNT
7
11
5
8
12
10
18
16
17
Fig. 1
15. Magnification changer
16. Handle
17. Common Main Objective
18. Magnichanger inclination movement lock
19. Illumination Control Knob
20. Fine focusing knob
21. iVu Camera inlet
22. On/Off switch
23. Power inlet
Prima ENT/DNT
Catalog no. 6138000-000
Model : Prima DNT
19
21
9
14
15
20
Issue 1.5
Printed on Feb.26,2019
