PRODUCT DESCRIPTION

1. Wheel with Brakes
2. Metal Base
3. Column
4. Swivel arm
5. Suspension arm
6. Swivel Arm Locking Knob
7. Suspension arm movement locking knob
8. Coupling movement locking knob
9. Suspension arm hydraulic movement lock
10. Suspension arm spring tension adjustment
11. Swivel arm cover
12. Binocular head with eyepieces
6210000-795
10
4
11
20
6
3
Fig. 1
5
9
8
7
17
13
14
2
1
13. Magnichanger
14. Handle
15. Common Main Objective
16. Illumination Control Knob
17. Magnichanger tiltation control knob
18. Inlet for LABOMED camera
19. Fine focusing knob
20. On/Off switch
Prima Mµ
16
12
18
15 19
