- Page 1 Prima OPH User Manual Ophthalmic Microscopy To ensure proper use of this instrument as well as to avoid injury while operating instrument, understanding this manual completely before use is highly recommended.
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION SAFETY INSTRUCTIONS SPECIAL INSTRUCTIONS UNPACKING DESCRIPTION OF PARTS SYSTEM DIAGRAM INSTRUCTIONS 7-10 ELECTRICAL CONNECTIONS CONTROLS INSTRUCTIONS FOR USING THE MICROSCOPE 10.1 SETTING UP MICROSCOPE 10.2 SETTING UP MAGNIFICATION HOW TO FOCUS THE OBJECT CHANGING THE OBJECTIVES AND EYEPIECES ADJUSTMENT OF TENSION WHILE USING ACCESSORIES DISINFECTION AND STERILIZATION CLEANING AND SERVICING... -
Page 4: Introduction
INTRODUCTION The LABOMED Prima OPH is an Ophthalmic microscope, which is adaptable for different surgical needs without compromise to performance. The microscope provides extremely high optical image quality, good depth of focus and wide field of view for precise surgery. Illumination control, inbuilt tilt, adjustment of the observation head help to reduce the surgeon’s work fatigue and allow comfortable use over long period. -
Page 5: Safety Instructions
Very important : For identification, service people must know the serial number of the microscope. Intended Use: The Prima OPH is a universal instrument for operative and diagnostic medical use. It is useful for optimal illumination and magnification of the attendance area with the possibility of: 1. Manual variations of magnification 2. -
Page 6: Special Instructions
SPECIAL INSTRUCTIONS Before every use and after re-equipping the instrument Check all Electrical connections. Attach sterilized covers, panels or caps which have been re-moved or opened. Pay special attention to labels on the instrument, such as caution label, warning triangles with exclamation marks or notes. -
Page 7: Unpacking
Prima OPH UNPACKING The appliance is delivered in sub-assembled groups along with one set of Installation Kit and one instruction / service manual. Please check following at the time of unpacking 1. Mobile supporting base with castor wheels, or as ordered 2. -
Page 8: Description Of Parts
DESCRIPTION OF PARTS 1. Observation Head 13. Swivel Arm 2. Eyepieces 14. Swivel Arm Locking Knob 3. CMO - Common Main Objective 15. Illumination Box 4. Fibre Optic Cable 16. Lamp Changing Knob 5. X-Y Coupling 17. On/Off switch for Foot Control 6. -
Page 9: System Diagram
SYSTEM DIAGRAM A616500-811 613800-815 Ad- 613400-820 612086-600 6122016 6122020 6122012 1271094 A6122015-800 A612086-400 6136000-900 6135000-800 6134105-102 6134105 6134100-800 6133176-00 6133201-000 6133251-000 6135000-809 6135000-909 6137300 6165000-817 6137200 6137500 6137100... -
Page 10: Instructions
Prima OPH INSTRUCTIONS 7.1 Pull out the base from the wooden pallet by removing two nuts with the help of spanner provided. 7.2 Remove allen screws from bottom side of the pillar. 7.3 Put the pillar on the base and align it with the pillar guide pin (A). - Page 11 Prima OPH 7.6 Firmly tight the safety lock screw provided on the suspension arm by using allen wrench 3mm. See fig 7.7 Remove four allen screws from the illumination box before mounting it on pillar. 7.8 Fix the illumination box on the pillar only after having Fig.
- Page 12 Prima OPH 7.11 Install the microscope coupling to the suspension arm prior to installing the head and eyepieces. Before installing, loosen the coupling locking knob (A) and safety position screw (B).Slide in the carrier shaft to the suspension arm and screw it with locking nut.
-
Page 13: Electrical Connections
Prima OPH 7.19 Assemble fibre optic cable into the hole provided at the backside of magnichanger assembly by gently pushing it in, as shown in fig 13. A click sound will confirm correct position. 7.20 Plug in the wire for foot control into the illumination box. -
Page 14: Controls
It is located on the right hand side of illumination box. If lamp blows off during the use of microscope, the Prima OPH is provided with a spare lamp. Lamp changing knob connects to the Lamp II for smooth running of the operation by turning it anti-clockwise. -
Page 15: Instructions For Using The Microscope
INSTRUCTIONS FOR USING THE MICROSCOPE 10.1 Setting up of Microscope: 10.1.1 Lock all the brakes on base wheels after setting up of microscope on the attendance area for stability. 10.1.2 Adjust tension on suspension arm using tension adjustment screw as per your convenience by turning the knob clock wise or anti-clock wise. -
Page 16: How To Focus The Object
How to focus the object 1. Adjust both the eyepieces to ‘0’ diopter adjustment. 2. Adjust IPD of the observation head using IPD scale. 3. Bring highest magnification factor in the click stop position using one of the knobs provided at the magnichanger unit. -
Page 17: Cleaning And Servicing
Prima ENT CLEANING AND SERVICING 15.1 Cleaning of optical surfaces: Remove coarse dirt particle with a clean dry air from optics outer surfaces (Objectives, Eyepieces). Moisten smooth cotton cloth with lens cleaning agent and wipe on the lens surface gently starting from the middle of the lens to the outer edge. 15.2 Cleaning of mechanical surfaces: All mechanical surfaces of the equipment can be cleaned by wiping with a moist cloth. -
Page 18: Troubleshooting Table
Prima OPH TROUBLESHOOTING TABLE Problem Possible Cause Remedy No Illumination at all Power cable not plugged Plug in power cable. Power switch not pressed Press power switch Defective instruments fuse Change instrument fuse Defective power cable Change power cable Line power failure... - Page 19 Prima OPH Problem Possible Cause Remedy Thermal cut-off in lamp Clean thermal cut-off with a housing is contaminated. dry brush; blow it clean, if necessary Defective fan. Failure of Contact service dept. system electronics. Illuminate surgical field using an Or illuminator. Contact service dept.
-
Page 20: Technical Specification
Prima OPH SPECIFICATIONS Technical Data (Specifications) Binocular tubes 45° inclined Eyepieces WF 10x/16mm with eye guards; optional WF 12.5x/16mm; WF 16x/16mm Apochromatic Magnichanger 0.4x, 0.6x, 1.0x, 1.6x & 2.5x Objective f=200, motorized fine focus Light source 15V/150W halogen, twin lamp Built-in filters Green &... - Page 21 Dimensions...
- Page 22 Email: Info@nyscopes.com www.microscopeinternational.com CA 94538 LABOMED and Prima OPH are registered trademarks of Labo America, Inc. With a policy of continuous development, Labo America, Inc. reserves the right to change design and specifications without prior notice. ISO 9001 : 2008 ©...
