Labomed Lx 300 User Manual

Clinical microscopy
Hide thumbs Also See for Lx 300:
Table of Contents

Advertisement

Quick Links

Download this manual
Lx 300
Clinical Microscopy
User Manual
To ensure proper use of this instrument as well as to avoid injury while operating
Instrument, understanding this manual completely before use is highly recommended.
Part No: 9136001-795
Issue 1.2
Printed on Oct,2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lx 300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Labomed Lx 300

Summary of Contents for Labomed Lx 300

  • Page 1 Lx 300 Clinical Microscopy User Manual Part No: 9136001-795 To ensure proper use of this instrument as well as to avoid injury while operating Issue 1.2 Instrument, understanding this manual completely before use is highly recommended. Printed on Oct,2019...

  • Page 3: Table Of Contents

    Lx 300 TABLE OF CONTENTS 1. INTRODUCTION 2. SAFETY INFORMATION 3. Lx 300 BINOCULAR 4. Lx 300 TRINOCULAR 5. UNPACKING YOUR MICROSCOPE 6. STANDARD COMPONENTS 7. OPTIONAL ACCESSORIES 9-11 8. INITIAL SETUP 9. ASSEMBLY 13-14 10. SUMMARY OF BRIGHT FIELD OBSERVATION PROCEDURE 11.

  • Page 4: Introduction

    Lx 300 INTRODUCTION The Lx 300 is a clinical microscope reflecting a modern design as well as the latest in optical and mechani- cal advancements. Designed for professionals as well as clinicians, this microscope offers many features and functions with excellent ergonomics for a fatigue free usage. Here are a few points highlighting the benefits of the Lx 300: -Extra clarity and contrast is provided through a 360°...

  • Page 5: Safety Information

    Do not place microscope on a flexible surface, as this could result in blocking the air vents and cause Overheating. 4. Always use the power cord provided by LABOMED. If the proper power cord is not used, product safety performance cannot be warranted.
  • Page 6 Lx 300 Caution If the microscope is used in a manner not specified by this manual, the safety of the user may not be warranted. In addition, the equipment may also suffer damage. Always use the equipment as outlined in this instruction manual.
  • Page 7 Lx 300 CARE & MAINTENANCE Your microscope had been engineered for a long and safe operational life with the least amount of main- tenance required. In general, routine maintenance is limited to keeping the microscope working parts lubricated and optics clean. Always cover the microscope with the provided dust cover when not in use.

  • Page 8: Lx 300 Binocular

    Lx 300 Lx 300 BINOCULAR Eyepieces Binocular viewing tube, 45° inclined° Revolving nosepiece Objectives Specimen holder Mechanical stage Abbe condenser Filter holder Coarse and fine focus knob On/off intensity regulator X-Y movement control knob Issue 1.2 9136001-795 Lx 300 Printed on Oct,2019...

  • Page 9: Lx 300 Trinocular

    Lx 300 Lx 300 TRINOCULAR Trinocular Port Eyepieces Trinocular viewing tube, 30° inclined° Revolving nosepiece Objectives Specimen holder Mechanical stage Abbe condenser Filter holder Coarse and fine focus knob On/off intensity regulator X-Y movement control knob Issue 1.2 9136001-795 Lx 300...

  • Page 10: Unpacking Your Microscope

    Lx 300 UNPACKING YOUR MICROSCOPE Power Cord Observation head Eyepieces Microscope Arm 9136001-795 Lx 300 Issue 1.2 Printed on Oct,2019...

  • Page 11: Standard Components

    Lx 300 STANDARD COMPONENTS After removing your microscope from its packaging, make sure that all of the following contents are present. “Please note that the contents of your microscope may vary as the optional configuration, contrasting method or viewing body opted for may not be of the standard configuration highlighted here”.

  • Page 12: Optional Accessories

    Lx 300 OPTIONAL ACCESSORIES SYSTEM DIAGRAM OF OPTIONAL ACCESSORIES VEGA CMOS CAMERA ATLAS CMOS CAMERA TOUCH SCREEN C-MOUNT ATLAS C-MOUNT VEGA C-MOUNT TOUCH SCREEN WF 10x WF 16x WF 20x BINOCULAR HEAD TRINOCULAR HEAD RP 4x RP 10x RP 20x...
  • Page 13 Lx 300 OPTIONAL EYEPIECES 10X eyepieces are provided. To replace: 1. Pull out the 10x eyepieces out from the observation heads Ocular tube. 2. Insert desired eyepieces in empty ocular tube. Fig. 5 PHASE TURRET 1. Remove the condenser from its position by loosening the thumb screw (1) on right side of the condenser bracket as shown in figure 6.
  • Page 14 Lx 300 2. Place the polarizer shown as (1) in figure. 9 on the illuminat- ion assembly shown as (2). Fig. 9 3. Fix the polarizer by tightening the screw provided. Refer figure. 10. Fig. 10 Issue 1.2 Lx 300...

  • Page 15: Initial Setup

    Lx 300 INITIAL SETUP OBJECTIVES Objectives are factory set. Objectives are par-centered and par-focalised during assembly. All objectives have been secured for a tight fit to prevent them from coming loose during transit. To remove an objective, rotate it counterclockwise while holding it with a rubber grip to avoid any slippage.

  • Page 16: Assembly

    Lx 300 ASSEMBLY PROCEDURE FOR LED REPLACEMENT Figure 15 1. Pull out two decorative caps (shown as 9) from back cover plate. 2. Using Cross head screw driver, unscrew two screws (shown as 9) to detach back cover plate from stand.
  • Page 17 Always use the designated Fuse. Using a fuse other than those Fig. 17 specified by LABOMED may lead to a fire hazard. CAUTION: For Fuse replacement Set the main switch to “O”(OFF), disconnect the power cord from the wall outlet.

  • Page 18: Summary Of Bright Field Observation Procedure

    Lx 300 SUMMARY OF BRIGHT FIELD OBSERVATION PROCEDURE Flip the main switch to “ON” Place the specimen on the stage. Fuse Holder Main switch Engage the 10X objective in the light path. Bring the specimen in focus. Adjust the observation tube and eyepieces Adjust the interpupillary distance.

  • Page 19: Detailed Observation Procedure

    Lx 300 DETAILED OBSERVATION PROCEDURE TURNING THE LAMP ON 1. Flip the main switch to “I” (ON) as shown in figure 19. Fig. 19 2. Rotating the light intensity adjustment knob (Fig. 20) in the direction of the arrow increases brightness and rotating knob in the opposite direction decreases brightness.
  • Page 20 Lx 300 Cover glass Cover glass This is the glass plate paced on the specimen. For optimum optical performance, the cover glass thickness, which is the distance from its surface to the specimen surface, should be 0.17mm. Slide glass Slide glass Fig.
  • Page 21 Lx 300 ADJUSTING THE INERPUPILLARY DISTANCE (IPD) The inter-pupillary distance adjustment consists of regulating the two eyepieces to align with both eyes’ pupils so that you can observe a single microscope image through two eyepieces in stereo vision. This greatly helps to reduce fatigue and discomfort during observation.
  • Page 22 Lx 300 CENTERING THE CONDENSER The condenser is fixed and cannot d-center. In case of any error, remove the condenser by loosening thumb screw and Re-install the same. Fig. 29 ADJUSTING THE CONDENSER POSITION AND APERTURE IRIS DIAPHRAGM The condenser is most often used in the highest position. If the observed field of view is not bright enough, brightness may be improved by lowering the condenser slightly.
  • Page 23 USING THE 100X IMMERSION OBJECTIVE The designated immersion oil should be in contact with the cover lens of the 100X immersion objective. If not, the specimen will appear distorted and dull. It is recommended that LABOMED immersion oil is always used. Immersion Process 1.

  • Page 24: Troubleshooting Guide

    Under certain conditions, performance of the unit may be adversely affected by factors other than defects. If problems occur, please review the following list and take corrective action as needed. If problem Persists, please contact LABOMED or your local LABOMED dealer. OBSERVATION...
  • Page 25 Lx 300 OBSERVATION CAUSE REMEDY Set the specimen correctly with the The specimen slide is upside down 8. Objective hits the specimen when cover glass facing upwards an objective is switched to a higher magnification objective The cover glass is too thick Use a cover glass with thickness of 0.17mm...

  • Page 26: Specifications

    Lx 300 SPECIFICATIONS 1. Illumination Built-in illumination system LED 2. Focusing mechanism Stage height adjustment mechanism Fine adjustment scale: 3.0µm per graduation Fine adjustment stroke: 0.3mm per turn Total stroke: 12.7mm Co-axial coarse and fine focusing on ball drive 3. Revolving nose piece...
  • Page 27 Revision History Rev. No. Date of Release DCR # Change App. By DCR/06/19 Trinocular version 29/6/19 S. Bal Included DCR/14/19 Removal of Bulb 23/10/19 S. Bal Information...
  • Page 28 Labo America Inc. 920 Auburn Court Fremont, CA 94538 U.S.A. Phone: 510-445-1257 Fax: 510-991-9862 E-mail: sales@laboamerica.com www.laboamerica.com EU REP. Labomed Europe Essebaan 50 NL-2908 LK Capelle a/d IJssel The Netherlands Tel: +31 (0)10 4584222 Fax: +31 (0)10 4508251 E-mail: info@labomedeurope.com LABOMED...
