20. TECHNICAL SPECIFICATIONS
Binocular Tubes
Eyepieces
Magnichanger
FOV (Field of View)
Objective
Built-in filters
Vertical Movement of Arm
Microscope Carrier
Accessories
Light Source
Power Consumption
Input Voltage
Stand
Elevation Stroke
Stand Height in Horizontal Position
Base (Dimensions)
Stand Height
Net Weight:
Microscope arm with Magnichanger
Head and Eyepieces
H-Base
Floor Column
Ceiling Mount Column
(for standard 3m ceiling mount)
Wall Mount Bracket
Ceiling Mount Bracket
30
6137000-795
Ergo viewing tube 0° - 210° (tiltable), IPD 50-75mm
Optional: Straight viewing tube 90°, IPD 55-75mm
WF 10x/18mm with retractable eye guards,
diopter adjustment ± 5mm and diopter lock
Optional: WF 12.5x/18mm; fixed eye guards.
5 step: 0.4x, 0.6X, 1.0X, 1.6X & 2.5x;
15° - 2.5° (80-13mm)
f= 250mm, manual fine focus
Yellow or Green
500mm
120° Carrier
Double Beam Splitter and
Camera Adapters.
50W LED; Maximum intensity 80,000 LUX
130W Maximum
100V-240V; 50/60 Hz
Stable and sturdy H-base stand with 2 lockable
wheels.
570mm
1100mm
600mm width
629mm length
1733mm
16.5 Kg
1 Kg
58 Kg
9 Kg
8 Kg
12 Kg
9 Kg
Prima ENT/DNT
Prima ENT/DNT
