USE OF ACCESSORIES
FLOOR MOUNT
1. Install double beam splitter by replacing the binocular tube (straight or ergo).
2. Total four accessories are provided as follows
2.1 DSLR camera adapter for Nikon, Canon and Sony
2.2 CCD camera adapter for Mintron.
2.3 Adapter for Sony Handy-Cam.
2.4 Assistoscope for assistant viewing
3. Install any one or two accessories on any side (Left or right) of the beam splitter
4. Reinstall binocular tube (straight or ergo) on double beam splitter.
6137000-795
CMO 250
CMO 350
CMO 400
CCD CAMERA
ADAPTER
FOOT CONTROL Z AXIS
Fig. 18
Prima ENT/DNT
Part No.: 6137000-000
Model: Prima ENT
STRAIGHT
BINOCULAR TUBE
DBS
DOUBLE IRIS
ASSISTOSCOPE
Prima ENT/DNT
SONY HANDY CAM
DSLR CAMERA
ADAPTER
ADAPTER
21
Issue 1.5
Printed on Feb.26,2019
