The eBOX671-885-FL is convenient for your various hardware configurations, such as
Processor, DRAM, HDD (Hard Disk Drive), SSD (Solid State Drive), CFast
Express Mini Card modules. The chapter 2 will show you how to install the hardware.
2.1
Installing the CPU Processor
Step 1 Turn off the system, and unplug the power cord.
Step 2
There are four screws on the top heatsink are used to fasten the
heatsink to the chassis.
Step 3 Loosen these screws to remove the top heatsink.
Hardware Installation
eBOX671-885-FL Series User's Manual
HARDWARE INSTALLATION
CHAPTER 2
TM
card or PCI
11
