Elnec JetProg User Manual page 91

F11
F12
Arrow keys
Home/End
PgUp/PgDn
Ctrl+PgUp/PgDn jump on start / end current page
Ctrl+Home/End jump on start / end current device
Backspace
Note: characters 20H - FFH (mode ASCII) and numbers
0..9, A..F (mode HEX) immediately changes content of edit
area.
Warning: Editing of ASCII characters for word devices is
disabled.
Print buffer
This command allows write selected part of buffer to printer
or to file. Program uses at it an external text editor in which
selected block of buffer is displayed and can be printed or
saved to file, too. By default is set simple text editor
Notepad.EXE, which is standard part of all versions of MS
Windows.
In Print buffer dialog are following options:
Block start
Defines start address of selected block in buffer.
Block end
Defines end address of selected block in buffer.
External editor
Defines path and name of external program, which has to
be used as text viewer for selected block of buffer. By
default is set simple text editor NOTEPAD.EXE, which is
standard part of all versions of MS Windows. User can
define any text editor for example WORDPAD.EXE, which
is able to work with large text files. In user defined text
editor user can print or save to file selected block of buffer.
The external editor path and name is saved automatically
to disk.
Find text dialog box
Enter the search string to Find to text input box and choose
<OK> to begin the search or choose <Cancel> to forget it.
switch the mode of buffer data view
between 8 bit and 16 bit view. It can be
also do by mouse clicking on the button
to the right of View/Edit mode buffer
indicator. This button indicates actual
data view mode (8 bit or 16 bit), too.
checksum dialog allows to count
checksum of selected block of buffer
change mode view / edit
move cursor up, down, right and left
jump on start / end current line
jump on previous / next page
move cursor one position left (back)
91
Software
