Connecting PREPROM-02aLV
programmer to PC
Switch off the PC and programmer. Insert the connection
cable, included in the PREPROM-02aLV programmer delivery,
to the free printer port of PC. If your computer is equipped with
only one printer port, substitute the programmer cable for the
printer cable. Connect the opposite cable end to the
programmer. Screw on both connectors to counterconnectors.
This is very important mainly for the connector to programmer.
Though replacing the printer cable by the programmer cable is
uncomfortable, it is not recommended to operate the
PREPROM-02aLV programmer through a mechanical printer
switch. Use of an electronic printer switch isn't possible.
Connect the mains connector of the power supply (or wall-plug
power supply self) to a mains plug, connect the connector to
the programmer's connector labeled 12VDC. Then, on the
programmer lights up LED POWER and the programmer
PREPROM-02aLV is ready to run. Next switch on the PC and
run the control program.
Caution! If you don't want to switch off your PC when
connecting the PREPROM-02aLV, proceed as follows:
• When connecting the programmer to the PC: FIRST insert
the communications cable and THEN the power-supply
connector.
• When disconnecting the programmer from the PC: FIRST
disconnect the power-supply connector and THEN the
communication cable.
