10/100/1000Base-T Ethernet Port Led; 100/1000Base-X Sfp Port Led - HP A5500 HI Series Installation Manual

Hide thumbs

Advertisement

Port
mode
(Mode) status

10/100/1000Base-T Ethernet port LED

Each 10/100/1000Base-T auto-sensing Ethernet port has a status LED to show port operating status and
activities. The port mode LED indicates the type of port status information (for example, port rate or
duplex mode) that the port LEDs are showing. You can use the port LED mode switching button to change
the type of displayed port information.
Table 18 10/100/1000Base-T Ethernet port LED description
Port
mode
(Mode) status
Steady
green
mode)
Steady yellow (duplex
mode)

100/1000Base-X SFP port LED

Each 100/1000Base-X SFP port has a status LED to show port operating status and activities. The port
mode LED indicates the type of information (for example, port rate or duplex mode) that the port LEDs are
showing. You can use the port LED mode switching button to change the type of displayed port
information.
Management
LED
Ethernet
port
(ACT/LINK) status
Flashing yellow (3 Hz)
Off
LED
Port LED status
Steady green
(rate
Steady yellow
Flashing yellow (3 Hz)
Off
Steady green
Steady yellow
Flashing yellow (3 Hz)
Off
LED
Description
POST has failed on the port.
No link is present on the port.
Description
The port is operating at 1000 Mbps. The port LED fast
flashes when the port is sending or receiving data.
The port is operating at 10/100 Mbps. The port LED
fast flashes when the port is sending or receiving data.
POST has failed on the port.
No link is present on the port.
The port is operating in full duplex mode. The port LED
fast flashes when the port is sending or receiving data.
The port is operating in half duplex mode. The port
LED fast flashes when the port is sending or receiving
data.
POST has failed on the port.
No link is present on the port.
54
