HP A5820X-24XG-SFP+ Quickspecs

A5820 series.
Hide thumbs
QuickSpecs
Overview
Models
Models
Models
Models
HP 5820-14XG-SFP+ Switch with 2 Slots
HP A5820X-24XG-SFP+ Switch
HP 5820AF-24XG Switch
Key features
Key features
Key features
Key features
For enterprise core, distribution, data center
Up to 24 ports of 10 GbE per unit/194 per stack
Flex-Chassis—modular resiliency
Cut-through switching for very low latency
Hot-swappable I/O, power supplies, and fans
Product overview
Product overview
Product overview
Product overview
The HP 5820 Switch Series features advanced Flex-Chassis switches that deliver a unique combination of unmatched 10 Gigabit
Ethernet, Fibre Channel over Ethernet (FCoE) connectivity, high-availability architecture, full Layer 2/3 dual-stack IPv4/IPv6, and
line-rate, low-latency performance on all ports. Extensible embedded application capabilities enable these switches to integrate
services into the network, consolidating devices and appliances to simplify deployment and reduce power consumption and rack
space. Extremely versatile, the switches can be used in high-performance, high-density building or department cores as part of a
consolidated network; for data center top-of-rack server access; or as high-performance Layer 3, 10-GbE aggregation switches in
campus and data center networks.
Features and benefits
Features and benefits
Features and benefits
Features and benefits
Quality of Service
Quality of Service
Quality of Service (QoS)
Quality of Service
Powerful QoS feature
Powerful QoS feature
Powerful QoS feature: creates traffic classes based on access control lists (ACLs), IEEE 802.1p precedence, IP, DSCP or Type
Powerful QoS feature
of Service (ToS) precedence; supports filter, redirect, mirror, or remark; supports the following congestion actions: strict priority
(SP) queuing, weighted round robin (WRR), weighted fair queuing (WFQ), weighted random early discard (WRED), weighted
deficit round robin (WDRR), and SP+WDRR
Integrated Network Services: with support for Open Application Architecture (OAA) modules, extends and integrates
Integrated Network Services:
Integrated Network Services:
Integrated Network Services:
application capability into the networtk
Ring Resiliency Protection Protocol
Ring Resiliency Protection Protocol (RRPP): provides fast recovery for ring Ethernet-based topology; ensures consistent
Ring Resiliency Protection Protocol
Ring Resiliency Protection Protocol
application performance for applications such as VoIP
Management
Management
Management
Management
Remote configuration and management: is available through a secure Web browser or a command-line interface (CLI)
Remote configuration and management
Remote configuration and management
Remote configuration and management
IEEE 802.1ab LLDP discovery
IEEE 802.1ab LLDP discovery
IEEE 802.1ab LLDP discovery
IEEE 802.1ab LLDP discovery: advertises and receives management information from adjacent devices on a network
USB support:
USB support
USB support
USB support
File copy
File copy: allows users to copy switch files to and from a USB flash drive
File copy
File copy
DHCP options
DHCP options
DHCP options: server (RFC 2131), client, snooping, and relay
DHCP options
SNMPv1, v2c, and v3
SNMPv1, v2c, and v3
SNMPv1, v2c, and v3
SNMPv1, v2c, and v3: facilitate centralized discovery, monitoring, and secure management of networking devices
sFlow: provides scalable, ASIC-based network monitoring and accounting; this allows network operators to gather a variety of
sFlow
sFlow
sFlow
sophisticated network statistics and information for capacity planning and real-time network monitoring purposes
Network Time Protocol
Network Time Protocol (NTP): synchronizes timekeeping among distributed time servers and clients; keeps consistent
Network Time Protocol
Network Time Protocol
timekeeping among all clock-dependent devices within the network so that the devices can provide diverse applications based
DA - 13791
Worldwide — Version 6 — September 26, 2011
HP A5820 Switch Series
HP A5820 Switch Series
HP A5820 Switch Series
HP A5820 Switch Series
JC106A
JC102A
JG219A
Page 1

Advertising

   Related Manuals for HP A5820X-24XG-SFP+

   Summary of Contents for HP A5820X-24XG-SFP+

  • Page 1

    Product overview Product overview The HP 5820 Switch Series features advanced Flex-Chassis switches that deliver a unique combination of unmatched 10 Gigabit Ethernet, Fibre Channel over Ethernet (FCoE) connectivity, high-availability architecture, full Layer 2/3 dual-stack IPv4/IPv6, and line-rate, low-latency performance on all ports. Extensible embedded application capabilities enable these switches to integrate services into the network, consolidating devices and appliances to simplify deployment and reduce power consumption and rack space.

  • Page 2

    Resiliency and high availability Resiliency and high availability Data center–optimized design Data center–optimized design Data center–optimized design: HP 5820AF-24XG Switch (JG219A) supports front-to-back/back-to-front airflow for hot/cold Data center–optimized design aisles, rear rack mounts, and redundant hot-swappable AC or DC power and fans Manageability...

  • Page 3

    Defense-in-depth security Defense-in-depth security: provides integrated and distributed security enforcement that can be managed from a central location, such as the HP Intelligent Management Center (IMC) Advanced processor queuing mechanism: helps prevent denial-of-service (DoS) attacks, while DHCP snooping helps ensure...

  • Page 4

    Intelligent Resilient Framework Intelligent Resilient Framework Creates virtual resilient switching fabrics, where two or more switches perform as a single Layer 2 switch, and Layer 3 router Switches do not have to be co-located and can be part of a disaster recovery system...

  • Page 5

    QuickSpecs Technical Specifications HP 5820-14XG-SFP+ Switch with 2 Slots (JC106A) HP 5820-14XG-SFP+ Switch with 2 Slots HP 5820-14XG-SFP+ Switch with 2 Slots HP 5820-14XG-SFP+ Switch with 2 Slots Ports Ports Ports Ports 14 SFP+ 10-GbE ports; Duplex: full only 2 extended module slots 1 open module slot 4 RJ-45 auto-negotiating 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-...

  • Page 6: Technical Specifications

    1-year, 6 hour Call-To-Repair Onsite for hardware (HR563E) 1-year, 24x7 software phone support, software updates (HR562E) Refer to the HP website at: and product numbers. For details about services and response times in your area, please contact your local HP sales office.

  • Page 7

    IEEE 802.1X Port Based Network Access Control RFC 1492 TACACS+ RFC 2865 RADIUS (client only) RFC 2866 RADIUS Accounting Worldwide — Version 6 — September 26, 2011 HP A5820 Switch Series HP A5820 Switch Series HP A5820 Switch Series HP A5820 Switch Series Page 7...

  • Page 8

    Technical Specifications RFC 4293 MIB for IP RFC 4419 Key Exchange for SSH HP A5820X-24XG-SFP+ Switch HP A5820X-24XG-SFP+ Switch HP A5820X-24XG-SFP+ Switch HP A5820X-24XG-SFP+ Switch (JC102A) Ports Ports Ports Ports 24 SFP+ 10-GbE ports; Duplex: full only 4 RJ-45 auto-negotiating 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE- TX, IEEE 802.3ab Type 1000BASE-T)

  • Page 9

    1-year, 6 hour Call-To-Repair Onsite for hardware (HR563E) 1-year, 24x7 software phone support, software updates (HR562E) Refer to the HP website at: and product numbers. For details about services and response times in your area, please contact your local HP sales office.

  • Page 10

    Fan tray 2 fan tray slots The customer must order fan trays, as fan trays are not included with the switch. This system requires two same-direction airflow fan trays to function properly. The system should not be operated with only one fan tray for more than 24 hours.

  • Page 11

    JC681A is required Services Services Services Services Refer to the HP website at: and product numbers. For details about services and response times in your area, please contact your local HP sales office. Standards and protocols Standards and protocols Standards and protocols...

  • Page 12

    RFC 2865 RADIUS (client only) RFC 2866 RADIUS Accounting Secure Sockets Layer (SSL) SSHv2 Secure Shell Worldwide — Version 6 — September 26, 2011 HP A5820 Switch Series HP A5820 Switch Series HP A5820 Switch Series HP A5820 Switch Series Page 12...

  • Page 13

    HP 5820AF-24XG Switch (JG219A) HP 58x0AF 650W AC Power Supply HP 58x0AF 650W DC Power Supply HP 58x0AF Back (power side) to Front (port side) Airflow Fan Tray HP 58x0AF Front (port side) to Back (power side) Airflow Fan Tray DA - 13791 Worldwide —...

  • Page 14

    © Copyright 2010-2011 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
