Appendix A Technical specifications

Table 9
describes the technical specifications for the A5500 HI switches.
Table 9 HP A5500 HI switches technical specifications
Item
Dimensions (H × W × D)
Weight
Management ports
Fixed network ports (on
the front panel)
Expansion
card slots
Power supply slots
Input voltage
Minimum
consumption
Maximum
consumption
Chassis leakage current
compliance
Melting
current
power supply fuse
Cooling system
Operating temperature
A5500-24G-4SFP HI (2 slots)
43.6 × 440 × 360 mm
(1.72 × 17.32 × 14.17 in)
< 7.5 kg (16.53 lb)
1 console port, 1 management Ethernet port, both on the front panel
24 × 10/100/1000Base-T
auto-sensing Ethernet ports
4 × 100/1000Base-X SFP ports
2 × 1/10 Gbps SFP+ ports
interface
2 (SLOT1 and SLOT2), on the rear panel
2, on the rear panel
AC-input
Rated voltage range: 100 VAC to 240 VAC @ 50 Hz or 60 Hz
Max voltage range: 90 VAC to 264 VAC @ 47 Hz to 63 Hz
DC-input
Rated voltage range: –48 VDC to –60 VDC
Max voltage range: –36 VDC to –72 VDC
NOTE:
You can use the site –48 VDC power supply or an HP A-RPS800 (JD183A) or
A-RPS1600 (JG136A) RPS as the DC power source.
power
62 W
power
141 W
UL60950-1, EN60950-1, IEC60950-1, GB4943
AC-input: 3.15A/250V
of
DC-input: 8A/250V
4 built-in fans (3 for the chassis, 1 for interface card slot 1)
1 fan on each power supply
Side-to-side air flow
0°C to 50°C (32°F to 122°F)
A5500-48G-4SFP HI (2 slots)
43.6 × 440 × 420 mm
(1.72 × 17.32 × 16.54 in)
< 8.5 kg (18.74 lb)
2 (SLOT1 and SLOT2), on the rear panel
2, on the rear panel
94 W
191 W
41
48 ×10/100/1000Base-T
auto-sensing Ethernet ports
4 × 100/1000Base-X SFP ports
2 x 1/10 Gbps SFP+ ports
