System status LED
(SYS) status
Steady red
Steady red
Steady green

Management Ethernet port LED

The management Ethernet port has a port LED to show its operating status and activities. The port mode
LED indicates the type of information that the port LED is showing.
Table 17 Management Ethernet port LED description
Port
mode
(Mode) status
Steady green (rate
mode)
Steady
(duplex mode)
Seven-segment LED (Unit) status
The LED displays a flashing F character.
The LED displays a flashing t character.
The LED displays a capital C character.
The LED displays an S character.
The LED displays a lowercase c character.
The LED displays a number.

Management
LED
Ethernet
port
(ACT/LINK) status
Steady green
Steady yellow
Flashing yellow (3 Hz)
Off
Steady green
yellow
Steady yellow
LED
Description
The port is operating at 1000 Mbps. The port LED fast
flashes when the port is sending or receiving data.
The port is operating at 10/100 Mbps. The port LED fast
flashes when the port is sending or receiving data.
POST has failed on the port.
No link is present on the port.
The port is operating in full duplex mode. The port LED fast
flashes when the port is sending or receiving data.
The port is operating in half duplex mode. The port LED fast
flashes when the port is sending or receiving data.
53
Description
The switch is experiencing a fan
failure.
The switch is in an over-temperature
condition.
The switch is the command switch in a
cluster.
The switch is a member switch in a
cluster.
The switch is a candidate switch for a
cluster.
The member ID of the switch.
