KPA Ku-Band Indoor Solid-State Power Amplifier
Connectors and Pinouts
3.2
RF Connections
3.2.1
J1 RF IN / Tx IN Connectors
KPA-020IN Unit
3.2.2
J2 RF OUT Connector
KPA-040/-080/-100 Units
Connector Type
SMA
Connector Type
WR75G Waveguide Flange
3–3
Description
RF Signal
Description
RF Signal
Revision 1
MN/KPA.IOM
Direction
In
Direction
Out
