Comtech EF Data KPA-040 Installation And Operation Manual page 109

KPA Ku-Band Indoor Solid-State Power Amplifier
Appendix C
Command Arguments for
Parameter Type (Instr Code and Command or
Qualifier) Response to Query
Retrieve Next 5 N/A variable length
unread stored
Events
Remote Baud SBR= 4 bytes,
Rate alpha-numeric
Serial Number N/A 9 bytes, numerical
000000000 to
999999999
Description of Arguments
(Note that all arguments are ASCII numeric codes, i.e., ASCII codes between 48 and 57)
Query only.
Unit returns the oldest 5 Stored Events which have not yet been read over the remote control.
Reply format: {CR}Subbody{CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Subbody,
where Sub-body= ABCddmmyyhhmmss,
A being the fault/clear indicator.
F=Fault
C=Clear
I=Info
B being the fault type where:
1=Unit
2=RF
3=Log
C is Fault Code
0=+5V Power Supply
1=+7.5V Power Supply
2=+15V Power Supply
3=RF Power Supply 1 (KPA20 and KPA40)
4=RF Power Supply 2 (KPA20 and KPA40)
5=RF Power Supply 1 (KPA80, KPA100 and CPA)
6=RF Power Supply 2 (KPA80, KPA100 and CPA)
7=Fan #1
8=Fan #2
9=BUC LD
A=External Reference
B=Over Temperature
C=Temp Shutdown
D=+28V Power Supply
E=-5V Power Supply
If there are less than 5 events to be retrieved, the remaining positions are padded with zeros.
If there are no new events, the response is
>DEV?RNE_COMMAND NOT AVAILABLE'cr''lf'] RNE?
Command or Query.
Set remote baud rate as follows:
2400 = 2400 baud
4800 = 4800 baud
9600 = 9600 baud
19K2 = 19200 baud
38K4 = 38400 baud
Query only.
Used to Query the units 9 digit serial number.
Slave returns its S/N, in the form xxxxxxxxx.
Example: SNO=000000165
C–15
Revision 1
MN/KPA.IOM
Query
Response to Query
(Instr Code and
(Target to controller)
Qualifier)
RNE? RNE={CR}ABCddmmyy
hhmmss{CR}ABCddmm
yyhhmmss{CR}ABCdd
mmyyhhmmss{CR}ABC
ddmmyyhhmmss{CR}A
BCddmmyyhhmmss
(see Description of
Arguments)
SBR? SBR=xxxx
(same format as
command arguments)
SNO? SNO=xxxxxxxxx
(see Description of
Arguments)
