Comtech EF Data KPA-040 Installation And Operation Manual page 121

KPA Ku-Band Indoor Solid-State Power Amplifier
Appendix C
Packed FET Status Packed FET Status:
KPA-080
KPA-100
<DEV/PACRFS_'cr'
Confirmation: >DEV/PACRFS_aabbccddeeffgghhiijjkkllmm
nnooppqqrrssttuuvvwwxxyyzzal'cr''lf']
Where:
aa = FET1 current in Hex, formular:
FET1 = (aa * 3) mA
bb = FET2 current in Hex, formular:
FET2 = (aa * 3) mA
cc = FET3 current in Hex, scaled 100mV
dd = FET4 current in Hex, scaled 100mV
ee = FET5 current in Hex, scaled 100mV
ff = FET6 current in Hex, scaled 100mV
gg = FET7 current in Hex, scaled 100mV
hh = FET8 current in Hex, scaled 100mV
ii = FET9 current in Hex, scaled 100mV
jj = FET10 current in Hex, scaled 100mV
kk = FET11 current in Hex, scaled 100mV
ll = FET12 current in Hex, scaled 100mV
mm = FET13 current in Hex, scaled
nn = FET14 current in Hex, scaled
100mV per count
oo = FET15 current in Hex, scaled
100mV per count
pp = FET16 current in Hex, scaled
100mV per count
qq = FET17 current in Hex, scaled
100mV per count
rr = FET18 current in Hex, scaled
100mV per count
ss = FET19 current in Hex, scaled
100mV per count
tt = FET20 current in Hex, scaled
100mV per count
uu = FET21 current in Hex, scaled
100mV per count
vv = FET22 current in Hex, scaled
100mV per count
ww = FET23 current in Hex, scaled
100mV per count
xx = FET24 current in Hex, scaled
100mV per count
yy = FET25 current in Hex, scaled
100mV per count
zz = FET26 current in Hex, scaled
100mV per count
a1 = FET27 current in Hex, scaled
100mV per count
C–27
Revision 1
MN/KPA.IOM
per count
per count
per count
per count
per count
per count
per count
per count
per count
per count
100mV per count
