1.2 Display
1.3
Sockets
Connectors:
1
Conductivity measuring cell
2
pH/Redox electrode
3
Temperature probe
4
Reference electrode
5
Mains power supply (option)
Caution
Only connect probes to the instrument that cannot feed ex-
cessive voltages or currents (> SELV and > circuit with cur-
rent limiter). Almost all commercial probes - especially WTW
probes - meet these requirements.
Status line
Sensor symbol
Measured value display
Function and
temperature display
1
Overview
5
4
77
