Allen-Bradley 1336 FORCE User Manual page 202

Chapter 5
Programming Parameters
SCANport Process Trim Owner
[Trim Owner]
This parameter displays which SCANport
devices are currently issuing a valid
process trim command.
1 = Process Trim Input Present
0 = Process Trim Input Not Present
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
SCANport Ramp Owner
[Ramp Owner]
This parameter displays which SCANport
devices are presently issuing a valid ramp
command.
1 = Ramp Input Present
0 = Ramp Input Not Present
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
SCANport Clear Fault Owner
[Clr Fault Owner]
This parameter displays which SCANport
devices are presently issuing a valid Clear
Fault Command.
1 = Clear Fault Input Present
0 = Clear Fault Input Not Present
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
10 Volt In Filtr
[10 Volt In Filtr]
This parameter establishes the breakpoint
radian frequency for the 10 Volt Input.
Pot In Filtr
[Pot In Filter]
This parameter establishes the breakpoint
radian frequecy for the Pot Input.
mA In Filtr
[mA In Filter]
This parameter establishes the breakpoint
for the mA Input.
5–76
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Enums:
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Enums:
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Enums:
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
348
Source
Bits
None
0000 0000
0000 0000
0111 1111
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
349
Source
Bits
None
0000 0000
0000 0000
0111 1111
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
350
Source
Bits
None
0000 0000
0000 0000
0111 1111
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved, Leave Zero
352
x.x r/s
eng x 10 radian/sec.
0.0 r/s
0.0 r/s
200.0 r/s
353
x.x r/s
eng. x 10 radian/sec
0.0 r/s
0.0 r/s
200.0 r/s
354
x.x r/s
eng. x 10 radian/sec
0.0 r/s
0.0 r/s
200.0 r/s
