SCANport Direction Mask
[Direction Mask]
This parameter selects which SCANport
devices can issue a forward/reverse
command.
1 = Permit Control
0 = Deny Control
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
SCANport Start Mask
[Start Mask]
This parameter selects which SCANport
devices can issue a start command.
1 = Permit Control
0 = Deny Control
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
SCANport Jog Mask
[Jog Mask]
This parameter selects which SCANport
devices can issue a Jog command.
1 = Permit Control
0 = Deny Control
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
SCANport Reference Mask
[Reference Mask]
This parameter selects which SCANport
device can issue a reference command.
1 = Permit Control
0 = Deny Control
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
SCANport Clear Fault Mask
[Clear Fault Mask]
This parameter selects which SCANport
devices can issue a Clear Faults
command.
1 = Permit Control
0 = Deny Control
Bit 0 – TB3
Bit 1 – SCANport Device 1
Bit 2 – SCANport Device 2
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Enums:
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Enums:
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Enums:
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Enums:
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Enums:
Bit 3 – SCANport Device 3
Bit 4 – SCANport Device 4
Bit 5 – SCANport Device 5
Chapter 5
Programming Parameters
331
Sink
Bits
None
0111 1111
0000 0000
0111 1111
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved
332
Sink
Bits
None
0111 1111
0000 0000
0111 1111
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved
333
Sink
Bits
None
0111 1111
0000 0000
0111 1111
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved
334
Sink
Bits
None
0111 1111
0000 0000
0111 1111
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved
335
Sink
Bits
None
0111 1111
0000 0000
0111 1111
Bit 6 – SCANport Device 6 (Int Gateway)
Bit 7 – Reserved
5–73
