Over Setpoint 3
[Over Setpoint 3]
This parameter is used to specify the set-
point threshold for the Over Setpoint 3 bit
in Logic Status Hi.
Over Setpoint 4
[Over Setpoint 4]
This parameter is used to specify the set-
point threshold for the Over Setpoint 4 bit
in Logic Status Hi.
Setpoint Select
[Setpoint Select]
This parameter makes a selection between
actual speed or internal Iq current refer-
ence for the At/Over Setpoint parameters.
Each Setpoint Status bit can be set for ei-
ther option ( 0 = Actual Speed; 1 = Iq Ref-
erence).
Bit 0 = At Setpoint 1
Bit 1 = At Setpoint 2
Bit 2 = Over Setpoint 1
Bit 3 = Over Setpoint 2
Speed Setpoint Tolerance
[Speed Setpnt Tol]
This parameter establishes a hysteresis
band around the At Setpoints. It will be
used to determine when to update the Set-
point Bits in the Logic Status Hi (P57),
when configured for actual speed option.
Current Setpoint Tolerance
[Cur Setpoint Tol]
This parameter establishes a hysteresis
band around the Setpoints. It will be used
to determine when to update the Setpoint
Bits in Logic Status Hi (P57), when config-
ured for commanded current option.
Zero Speed Tolerance
[Zero Speed Tol]
This parameter establishes a band around
zero speed that will be used to determine
when to update the At Zero Speed bit in
the Logic Status Low (P56).
Logic Testpoint Data
[Logic Tstpt Data]
This parameter contains the logic control
testpoint data that has been selected by
the Logic Tstpt Sel parameter, P71.
5–40
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Enums:
Bit 4 = Over Setpoint 3
Bit 5 = Over Setpoint 4
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
64
Sink
+/– x.x%
4096 = 100.0% setpoint
+0.0 %
–800.0%
+800.0%
65
Sink
+/– x.x %
4096 = 100% setpoint
+0.0 %
–800%
+800%
66
Sink
Bits
bit clear = speed, set = current
0000 0000 0000 0000
0000 0000 0000 0000
0000 0000 1111 1111
67
Sink
x.x rpm
4096 = base speed
base sp / 100
0.0 rpm
base speed /10
68
Sink
x.x%
4096 = 100.0% Iq
2.0%
0.0%
20.0%
69
Sink
+/– x%
4096 = base speed
base speed / 100
0.0 rpm
8 x base speed
70
Source
Bits
None
0000 0000 0000 0000
0000 0000 0000 0000
1111 1111 1111 1111
