Allen-Bradley 1336 FORCE User Manual page 19

v1.xx
v1.xx
Not Compatible
v3.xx
Not Compatible
STADARD
ADAPTER
BOARD
v4.xx
Not Compatible
v5.xx
Not Compatible
MOTOR CONTROL BOARD
v2.xx
Compatible
Compatible with exception:
Torque Stop Configuration #58
non–functional.
Service Factor #94 non–functional.
Feedback Device Type #150
mode 7 non–functional.
Calculated Torque #267
non–functional.
Compatible with exception:
Torque Stop Configuration #58
non–functional.
Service Factor #94 non–functional.
Feedback Device Type #150
mode 7 non–functional.
Calculated Torque #267
non–functional.
Compatible with exception:
Torque Stop Configuration #58
non–functional.
Service Factor #94 non–functional.
Feedback Device Type #150
mode 7 non–functional.
Calculated Torque #267 non–functi.
Perunit Motor Curr #185 non–funct.
Perunit Motor Volt #186 non–funct.
Transistor Diag. #257 bit 12 non–funct.
Chapter 1
Introduction
v3.xx
Compatible with exception:
Drive Comm #9–19 non–linkable.
Drive Comm Tx/Rx #14–19 max
value 219.
Torque Stop Configuration #58 not
available.
Service Factor #94 not available.
Feedback Device Type #150 mode
7 not available.
Calculated Torque #267 not
available.
Precharge Timeout #225 min value 0
Compatible
Compatible with exception:
V3.04 VP must be used with V4.02
SA and V4.02 Language or higher
for B800 'H Frame' drive support.
Compatible with exception:
V3.04 VP MUST be used with V3.03 AP
and V3.03 Language or higher for B800
'H Frame' drive support.
Calculated Torque #267 non–functi.
Perunit Motor Curr #185 non–funct.
Perunit Motor Volt #186 non–funct.
Transistor Diag. #257 bit 12 non–funct.
v5.xx
Compatible with exception:
Drive Comm #9–19 non–linkable.
Drive Comm Tx/Rx #14–19 max
value 219.
Torque Stop Configuration #58 not
available.
Service Factor #94 not available.
Feedback Device Type #150 mode
7 not available.
Calculated Torque #267 not available.
Precharge Timeout #225 min value 0.
Perunit Motor Current #185 not
available.
Perunit Motor Voltage #186 not
available.
Transistor Diagnostics #257 bit 12
not available.
Iq Rate Limit #181 max value 30%.
Motor Overload Select #92 min
value 150%.
Motor Poles #233 max value 12.
Base Motor Speed #229 max val 6000.
Compatible with exception:
V3.04 VP must be used with V3.03
AP and V3.03 Language or higher
for B800 'H Frame' drive support.
Perunit Motor Current #185 not
available.
Perunit Motor Voltage #186 not
available.
Transistor Diagnostics #257 bit 12
not available.
Iq Rate Limit #181 max value 30%
Motor Overload Select #92 min value
150%.
Motor Poles #233 max value 12.
Base Motor Speed #229 max val 6000.
Compatible with exception:
V5.xx VP must be used with V4.02
AP and V4.02 Language or higher
for B800 'H Frame' drive support.
Perunit Motor Current #185 not
available.
Perunit Motor Voltage #186 not
available.
Transistor Diagnostics #257 bit 12
not available.
Iq Rate Limit #181 max value 30%
Motor Overload Select #92 min
value 150%.
Motor Poles #233 max value 12.
Base Motor Speed #229 max valu 6000.
Compatible
