Allen-Bradley 1336 PLUS Instruction Manual

Enclosure Installation
1336 PLUS, 1336
NEMA Type 1 Enclosure Kit
1336S/F/T-AAx and 1336S/F/T-AEx
This publication will guide you through installation of an IP 20
(NEMA Type 1) Enclosure Kit (1336S/F/T-AAx) or EMC Enclosure
Kit (1336S/F/T-AEx). Refer to the appropriate drive User Manual for
further information.
ATTENTION: This drive contains ESD (Electrostatic Dis-
!
charge) sensitive parts and assemblies. Static control pre-
cautions are required when installing, testing, servicing or
repairing this assembly. Component damage may result if
ESD control procedures are not followed. If you are not
familiar with static control procedures, reference A-B pub-
lication 8000-4.5.2, "Guarding Against Electrostatic Dam-
age" or any other applicable ESD protection handbook.
ATTENTION: To avoid a shock hazard, assure that all
!
power to the drive has been removed before proceeding with
the following procedure. In addition, verify that the DC bus
has discharged by measuring across the "+DC" and "–DC"
terminals of TB1 with a voltmeter. The voltage should be
0.0VDC.
ATTENTION: When a drive mounted HIM is not supplied
!
on enclosed IP 20 (NEMA Type 1) drives, the blank cover
plate (option HAB/HASB) must be installed to close the
opening in the front cover of the enclosure. Failure to install
the blank cover plate allows access to electrically live parts
which may result in personal injury and/or equipment dam-
age.
When a drive mounted HIM is supplied with enclosed IP
20 (NEMA Type 1) drives, but has been removed from its
mounting cradle for remote operation, the blank cover plate
must be installed in place of the HIM.
& 1336 FORCE™
PLUS
II
Instructions
