Chapter 5
Programming Parameters
Inverter Diagnostics Result #2
[Inverter Diag 2]
The results of the Transistor Diagnostic
Tests are given in parameters 258 & 259.
If any of the bits shown below are set, then
a problem with the associated test is
indicated.
0 = Transistor U upper shorted
1 = Transistor U lower shorted
2 = Transistor V upper shorted
3 = Transistor V lower shorted
4 = Transistor W upper shorted
5 = Transistor W lower shorted
Iq OFFSET
[Iq Offset]
This parameter contains the LEM U offset
required to null the current error. (no motor
current flowing) This offset is set automati-
cally by running the transistor diagnostics.
Id OFFSET
[Id Offset]
This parameter contains the LEM W offset
required to null the current error. (no motor
current flowing) This offset is set automati-
cally by running the transistor diagnostics.
Phase Rotation Current Reference
[Ph Rot Curr Ref]
This parameter sets the current reference
that will be used when the Phase Rotation
test is run (Parm 256, bit 1)
Phase Rotation Frequency Reference
[Phase Rot Freq Ref]
This parameter sets the frequency refer-
ence that will be used when the Phase
Rotation test is run (Parm 256, bit 1)
Motor Current Magnitude Feedback
[Motor Cur Fdbk]
Displays the actual RMS value of the motor
current as determined from the LEM cur-
rent sensors. This data is averaged and
updated on a 50 millisecond basis.
Motor Voltage Magnitude
[Motor Volt Fdbk]
Displays the actual Line–to–Line RMS val-
ue of motor voltage. This data is averaged
and updated on a 50 millisecond
basis.
5–64
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Enums:
6 = Current fdbk ph U offset too big
7 = Current fdbk ph W offset too big
8 = Transistor U upper open*
9 = Transistor U lower open*
10 = Transistor V upper open*
*See Parameter 257, bit 12
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Parameter Number
Parameter Type
Display Units
Drive Units
Factory Default
Minimum Value
Maximum Value
Parameter Number
263
Parameter Type
Sink
Display Units
x.x Hz
Drive Units
128 @ 1 Hz
Factory Default
3.0 Hz
Minimum Value
– 30.0 Hz
Maximum Value
+30.0 Hz
Parameter Number
264
Parameter Type
Source
Display Units
x.x Amp
Drive Units
Display units x 10
Factory Default
0.0 amps
Minimum Value
0.0 amps
Maximum Value
6,553.5 amps
Parameter Number
265
Parameter Type
Source
Display Units
x Volt
Drive Units
None
Factory Default
+ 0 Volt
Minimum Value
– 3,000 Volt
Maximum Value
+3,000 Volt
259
Source
Bits
None
0000 0000 0000 0000
0000 0000 0000 0000
1111 1111 1111 1111
11 = Transistor V lower open*
12 = Transistor W upper open*
13 = Transistor W lower open*
14 = Current feedback phase U open*
15 = Current feedback phase W open*
260
Sink
+/– x
None
+0
–100
+100
261
Sink
+/– x
None
+0
–100
+100
262
Sink
x.x%
4096 = 100.0% Motor Current
50.0%
0.0%
100.0%
