Appendix H: Label Requirements for Zone
Identification
For individual zones, the labelling of these zones must be in accordance with ULC/CAN S527-11 Table 2; of
which is partially included below:
LABEL DESIGNATIONS IN ENGLISH
XXX Alarm Signal Activation or
a
XXX Alarm Signal ON
a
XXX Alert Signal Activation or
a
XXX Alert Signal ON
a
XXX By-pass
a
XXX ON
a
XXX OFF
a
Building Safety or Bldg Safety
XXX
b
Emergency and building events
XXX
b
XXX
b
XXX Bypass
a
Activate XXX or equivalent followed
a
by
XXX
a
Remote Connection Bypass or
equivalent
Signal Circuit Trouble
Signal Silence Inhibit
Supervisory
XXX
a
Supervisory Signal Silence
Trouble
XXX Trouble
a
ａ ｒｅｐｌａｃｅ ＸＸＸ ｗｉｔｈ ｌｏｃａｔｉｏｎ ａｎｄ／ｏｒ ｄｅｖｉｃｅ ｓｐｅｃｉｆｉｃ ｄｅｓｃｒｉｐｔｉｏｎ．
ｂ ｓｕｃｈ ａｓ ａｌａｒｍｓ， ｌｉｆｅ ｓａｆｅｔｙ， ｓｕｐｅｒｖｉｓｏｒｙ， ｂｕｉｌｄｉｎｇ ｓａｆｅｔｙ ａｎｄ ｔｒｏｕｂｌｅ
100

Appendix H: Label Requirements for Zone Identification

DESCRIPTION OF FUNCTION
Circuit Or Area Evacuation Manual
Control
Circuit Or Area Alert Manual Control
Ancillary Bypass
Ancillary Device Indication
Ancillary Device Indication
Common Indication Associated With
Property And Building Safety
Specific Indication Associated With
Property And Building Safety
Common Indication Associated With
Emergency And Building Events
Specific Indication Associated With
Emergency And Building Events
Emergency Or Building Event Manual
Control
Bypass Output Function
Initiate Manual Control Function
Bypass Connection For Fire Service
Response
Signal Circuit Fault Indication
Prevent Silence Of Signal For A Preset
Time
Common Indication Associated With
Supervisory Inputs
Specific Indication Associated With
Supervisory Input
Manual Signal Silence Control For
Supervisory Signal
Common Trouble Signal Indicator
Specific, Circuit Or Area Trouble
Signal Indicator
