3 External connectors of DLT-V6210
Connectors under the cable cover
RSMA External Wi-Fi antenna interface
Power Power supply 12/24/48 nominal
Network 2 x network adapter (RJ45 connection jack) with
adapter 10/100/1000 Mbit per second
USB
2 x USB 2.0 Hi-Speed HOST A type, 5 VDC 500 mA
Fused at 0.5 A per channel
Serial COM Max. 115,200 Baud (16550A compatible, 16 byte FIFO)
Supports EIA-232-E on external 9-pin D-Sub connection
5V at Pin 9
CFast slot under the antenna cap
Opening the antenna cap:
− Loosen the two screws of the antenna cap using a Torx screwdriver.
− Carefully lift up the antenna cap.
− Exercise special care when
removing and re-inserting
the CFast card.
− Only use CFast cards that
have been approved by
Advantech-DLoG.
3
