Closing the antenna cap:
− Place the antenna cap back onto DLT-V6210. The antenna cap seal must not
be damaged; it must be seated correctly in the groove.
− Tighten the two screws of the antenna cap again (1 Nm torque).
4
Overview of operation elements
NOTE: Users of the DLT-V6210 must be trained by skilled personnel and
instructed about the operation of the device.
Operate the touchscreen with:
− Clean, dry fingers
− Clean, dry, thin gloves
− Suitable touch stylus
Function of the front keys (left side):
− Power on/off
− LCD Brightness up
− LCD Brightness down
LED indication:
System Status
System power on
System power off
System over/under
temperature
System thermal
sensor faulty
4
LED Status
Static on
Off
Blinking
0.2 sec. on / 0.8 sec. off
Blinking
0.5 sec. on / 0.5 sec. off
